Lifting Capacity: 1~12t or more
Lifting Height: 2~10m, customized
Outreach: 2.5~12m, customized
Class: European design A5/2m, option A3
Slew degree from 0 to 360°/270°/180°
Equipped with a lifting beam for boat
Specially designed to lift boat with protective functions
MAGICART’s Boat Jib Crane are small but powerful lifting tools for places like workshops, factories and marine environments. Their purpose is not only localized lifting but also handling of materials, which makes them perfect for confined places. Besides their strong build, they also come equipped with sophisticated control systems, hence, our cranes are always at your side delivering safe and reliable performance. Also, MAGICART boat lift Crane can be tailor-made according to customer needs, thus offering the best productivity and working efficiency. The design that is user-friendly enables easy installation and running. Rely on MAGICART for long-lasting, high-performance jib crane.
Lightweight body, Low purchase cost
Full safety protection, Easy maintenance
Low power consumption & operating cost
| Load Capacity (ton) | Outreach (m) | Max. Lifting height (m) | Duty Class |
| 1 | 3~6 | 3~8 | A3 or A5 |
| 2 | 5~35 | 3~25 | A3 or A5 |
| 3 | 5~35 | 3~25 | A3 or A5 |
| 5 | 5~35 | 3~25 | A3 or A5 |
| 8 | 5~35 | 3~25 | A3 or A5 |
| 10 | 5~35 | 3~25 | A3 or A5 |
| 12 | 5~35 | 3~25 | A3 or A5 |
| Customizable | Customizable | Customizable | Customizable |
| Power Supply: 380~460V, 50/60HZ, 3 Phase | |||
| FEM class: A3, A5 as standard | |||
