Capacity: 1~32t, can be 2 hoist or more
Span (rail gauge): 5~35m, customized
Lifting Height: 5~35m, customized
Class: European design A5, option A3
Powered via cable reel or diesel generator
Workshop, Concrete plant, all factories, etc.
For assembly, loading, unloading area, etc.
Run on the rail to cover whole area
Lightweight body, Low purchase cost
Low power consumption &operating cost
With hydraulic clamp to prevent sliding
With anti-tipping to prevent typhoons
| Capacity (ton) | Span (m) | Max Lifting height (m) | Class |
| 1 | 5 ~ 28.5 | 3 ~ 25 | A3 ~ A5 |
| 3 | 5 ~ 28.5 | 3 ~ 25 | A3 ~ A5 |
| 5 | 5 ~ 28.5 | 3 ~ 25 | A3 ~ A5 |
| 10 | 5 ~ 28.5 | 3 ~ 25 | A3 ~ A5 |
| 15 | 5 ~ 28.5 | 3 ~ 25 | A3 ~ A5 |
| 20 | 5 ~ 28.5 | 3 ~ 25 | A3 ~ A5 |
| 25~50 | 5 ~ 28.5 | 3 ~ 25 | A3 ~ A5 |
| Customizable | Customizable | Customizable | Customizable |
| • Power Supply: 380~460V, 50/60HZ, 3 Phase | |||
| • FEM class: A5 as standard, A3 as customized options | |||
