MAGICART has completed the on-site installation of two 90T Rail Mounted Gantry Cranes for a customer in the Middle East. Designed for heavy-duty lifting and material handling, the two cranes have a rated lifting capacity of 90 tons, a 30-meter span, and a maximum lifting height of 15 meters.
The project required reliable lifting equipment capable of handling heavy loads while providing stable and accurate movement across the working area. As Rail Mounted Gantry Cranes, the equipment operates along fixed rails, providing controlled traveling and stable positioning during lifting operations.
90T Gantry Cranes Designed for Heavy-Duty Lifting
Each 90 Ton Gantry Crane is engineered to provide stable lifting performance for demanding industrial applications. With a 30m span, the cranes can cover a wide working area, while the 15m lifting height provides sufficient vertical clearance for lifting and positioning large loads.
The rail-mounted configuration also allows the cranes to travel along a defined operating path. This structure is suitable for applications where repeatable movement and precise load positioning are important.
30m Span and 15m Lifting Height
The project configuration combines a 30m span with a 15m lifting height to meet the customer’s operational requirements. The crane structure, lifting system, traveling mechanism, and control system were manufactured and prepared according to the project specifications.
Professional On-Site Gantry Crane Installation
Following manufacturing and factory preparation, the two cranes were transported to the customer’s site in the Middle East for installation. MAGICART’s technical team supported the gantry crane installation, including equipment assembly, system connection, adjustment, and operational checks.
On-site installation is an important part of large lifting equipment delivery. Proper assembly and system adjustment help ensure that the crane structure, traveling mechanism, lifting system, and control functions work together as designed.
Engineering Support from Manufacturing to Installation
MAGICART provides support throughout the project process, from engineering and manufacturing to factory inspection, transportation preparation, and on-site installation. This project demonstrates the company’s ability to provide complete rail mounted gantry crane solutions for international industrial applications.
With project-specific engineering and technical support, MAGICART continues to provide reliable lifting equipment for customers across different markets and working environments.
